Function Device Laboratory

General Information

Aim of our laboratory: Social service and Contribution for human life

1. We contribute to the human race by progress of science and technology.
   We do not work for our reputation.
   All results and "know-how" disclosed to the public.
2. Education of students and bring up "engineer"

---

History of "Function Device Laboratory"

• 1998 Function Device laboratory established in this year.
• 1999 Research activities and experiments were started.

---

Policy

---

Research Field

• Electro and optical properties of Semiconductors
• Efficient devices of mutual conversion between light and electricity
• Functional Thin-film devices and thin-film technology
• Optoelectronic devices and photonic devices
• Electron Display Device, Drive system and Drive circuit

---

Laboratory Location

• Function Device Laboratory [room : A801、A802、A803] (extension 7881)

X-ray photoelectron Spectroscopy (XPS)
　　 Auger electron Spectroscopy (AES)

• High Technology Research Center

Semiconductor Analysis Room [room #: H-06] (extension 7766)
　　　 Deep Level Transient Spectroscopy (DLTS)
　　　 Carrier Profiler for wide band-gap material

Clean Room (class 1000) [room #: H-07 A] (extension 7767)
　　　Excimer Laser Ablation
　　　High Vacuum Evaporation for Organic Photoniccrystal

Clean Room (class 1000) [room #: H-07 B] (extension 7768)
　　　Ultra High Vacuum Evaporation

Clean Room (class 1000) [room #: H-07 C] (extension 7769)
　　　High Vacuum Electron-Beam Evaporation
　　　Load-lock system (EB evaporation -RF sputtering -Rapid Thermal Annealing)

Clean Room (class 100) [room #: H-07 D] (extension 7770)

• Helium Liquefier Room: [house 70] (extension 7990)


• Experimental room for our department [room #: 4214] (extension 7374)
  　　　 Vacuum Evaporation
  　　　   High Vacuum Evaporation for Organic Thin-Film Transistors
  　 　 High Vacuum Evaporation for Organic Light Emitting Diodes



---
